One exnon lamp 150W/200W YAG Jewelry Laser Welding Machine

Advantage

1.The YAG jewelry laser machiner is high precision (0.1-2mm spot size)welding method and laser beam is very thin.

2. The 150W laser welding machine’sfrequency can reach 20HZ.

3. Jewelry,glasses frame,mould,dental teeth needs laser welding way which have beautiful welding joints by this spot welding laser welding machine..

4.Jewelry laser welding machine is widely used in all kinds of metal like gold,sillver,bronze,aluminum.steel and titanium.

5. 150watt YAG laser welding machine is new product, This product can help you win client trust on high level jewelry welding industry

6.Our company manufactureand develope YAG pulsed  power supply which have big advantage in prices and after sale service.

7.24 hours and 7 days technical support can be offered.

8. Two lase welding head and 2 pcs fiber cable are optional

Specification

Product Name:  Mini Spot Gold Silver Jewelry Laser Welding Machine Factory Price

Model No. RW-150Y/RW-200Y

Laser Source: Nd YAG pulsed

Laser Wavelength: 1064nm

Rated Power: 150W/200W

Laser Energy :80J /100J

Pulse Width: 0.1-20ms

Pulse Frequency: less than 35Hz

Beam Diameter :0.1-3.0mm

Power Supply: 220V±10% /50Hz and 60Hz compatible

Observing System :microscope or CCD camera

Chamber Illumination: LED circle lamps

Parameters Memorization: 10 groups

Protection Alert: flow alert

Language Display: Chinese/English

Shield Gas Supply: One line(Argon)

Cooling System: External water chiller or built-in water chiller

Power Consumption: 6.5KW/ 7.5KW

Welding Chamber Dimension: 340mmx540mmx180mm(LxWxH)

Machine Dimensions :Welder:850mmx500mmx600mm (L*W*H)

Chiller:430x370x585mm(LxWxH)

Running Environment: 5℃-30℃, 5%-75% humidity

Net Weight :150kg(welder)+65kg(chiller)
