1000W 3D Fiber Laser Welding Tools

Feature

1. The 3D metal fiber welding tools’s output laser is stable which ensures weld consistency.

Also power density is high after laser focusing. Besides, the weld seam is smooth and beautiful, so the welding workpiece has no deformation and the welding is firm and no subsequent 2.Grinding process is required which saves time and cost.360 degree without dead angle micro soldering can be realized on this high precission fiber laser welding tools.

3.After the laser beam is focused, a small spot can be obtainedon this 1000W fiber laser welding tools which can be accurately positioned and used in the group welding of micro and small size workpieces for mass production. Mainly for the welding of thin walled materials and precision parts, it can realize spot welding, butt welding, stack welding, sealing welding, etc., high aspect ratio, small weld width, small heat affected zone, small deformation, fast welding speed, no need to be processed after welding or simply processed.

4.The butt welding fiber laser welding tools have fast welding speed, 2-10 times faster than traditional welding tools, one tools can replace at least 2 welders a year.

5. the 3D metal fiber welding tools also have long life working, safer and more environmentally friendly.

6.Laser welding is with low consumables for micro soldering.

Specification

1. Laser power 500W/800W/1000W/1500W/2000W/3000W

2. Fiber cable length: Default 10M, 15M cable is optional.

3 working way: continuous or modulation

4.Welding speed: 0-120mm/s

5.Cooling: water Industrial therm ostatic water tank

6.Working temperature: 15-35℃

7.Working humidity: less than 70% no condensation

8. Welding thickness: 0.5-3mm

9. Welding gap requirements: less than 0.5mm

10. Input votlage: 380V

Appliction

This fiber laser welding tools can be widely used in cabinets, kitchen, staircase elevator, shelf, oven, stainless steel door and window guardrail, distribution box, stainless steel home and other industries complex and irregular welding processed.
